材质：采用UL认可之尼龙66料制成，防火等级UL94V-2
适合温度：-40℃—85℃
颜色：黑色、白色，特殊颜色可定制
TYPE1
TYPE2
TYPE3
| 规号型号 | L长度 | W宽度 | 最大捆扎范围 Max.Bundle DIA.(mm) | 最小拉力 Min Tensile Strength | 适用孔径∅ | 机板厚度 | TYPE | |||
| Item NO. | (mm) | Panel | ||||||||
| Thickness | ||||||||||
| Inch | mm | LBS | KGS | mm | mm | |||||
| HYP-110MT | 4.33″ | 110 | 2.5 | 22 | 18 | 8.1 | 4.8 | 0.8~3.2 | TYPE1 | |
| HYP-130A | 5.12″ | 130 | 3.3 | 28 | 30 | 13.6 | 4.8 | 1.6~2.5 | TYPE1 | |
| HYP-130I | 5.12″ | 130 | 3.2 | 38 | 30 | 13.6 | 4 | 0.8~1.8 | TYPE2 | |
| HY-WPMT150I | 5.98″ | 152 | 3.4 | 32 | 40 | 18.2 | 4.7 | 1.3~2.5 | TYPE1 | |
| HYP-160I | 6.30″ | 160 | 3.6 | 38 | 40 | 18.2 | 4.5~4.8 | 0.8~2.0 | TYPE1 | |
| HYP-100ST | 3.94″ | 100 | 4.8 | 17 | 50 | 22.2 | 4.5 | 2.5~4.5 | TYPE1 | |
| HYP-135ST | 5.32″ | 135 | 4.8 | 25 | 50 | 22.2 | 6.4 | 0.8~3.2 | TYPE3 | |
| HYP-200ST | 7.87″ | 200 | 4.8 | 25 | 50 | 22.2 | 6.4 | 0.8~3.2 | TYPE3 | |
